Purpose-Built for the Players

Geared for gaming, but designed with much more in mind, the Legion 5i is purpose-built to do everything. The thin and light chassis pairs portability and performance, with up to the latest 12th Generation Intel® Core™ processors and NVIDIA® GeForce RTX™ 3070 Ti (140W) graphics. Now with Gen 4 PCIe SSD storage and 4800 MHz DDR5 memory, boost your battery life and performance for all-day action at work, at home, or on the go. With an up-to 15.6" WQHD (2560 x 1440) resolution screen at a 165 Hz refresh rate with only 3 ms response time and Legion Coldfront 4.0 cooling technology, you’ll be overclocking your game, not your noise. So get better, get balanced, and get gaming.

Performance Specifications

Performance
Processor: Intel® Core™ i7-12700H, 14C (6P + 8E) / 20T, P-core 2.3 / 4.7GHz, E-core 1.7 / 3.5GHz, 24MB
Graphics: NVIDIA® GeForce RTX™ 3060 6GB GDDR6, Boost Clock 1702MHz, TGP 140W
Chipset: Intel® SoC Platform
Memory: 2x 8GB SO-DIMM DDR5-4800
Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-4800
Storage: 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe®
Storage Support:
Up to two drives, 2x M.2 SSD
M.2 2242 SSD up to 512GB
M.2 2280 SSD up to 1TB
Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots
RAID Preset: None
Card Reader: None
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, Nahimic Audio
Camera: FHD 1080p with E-shutter
Microphone: 2x, Array
Battery: Integrated 80Wh
Power Adapter: 300W Slim Tip (3-pin)
Design
Display: 15.6" WQHD (2560x1440) IPS 300nits Anti-glare, 100% sRGB, 165Hz, Dolby® Vision™, G-SYNC®
Touchscreen: None
Color Calibration: No color calibration
Keyboard: 4-Zone RGB Backlit, English
Case Color: Storm Grey
Surface Treatment: Anodizing
Case Material: Aluminium (Top), PC-ABS (Bottom)
Dimensions (WxDxH): 358.8 x 262.35 x 19.99 mm (14.13 x 10.33 x 0.79 inches)
Weight: Around 2.4 kg (5.3 lbs)
Software
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Home & Student 2021
Connectivity
Ethernet: 100/1000M (RJ-45)
WLAN + Bluetooth: Wi-Fi® 6, 11ax 2x2 + BT5.1
Standard Ports:
1x Ethernet (RJ-45)
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
1x Thunderbolt™ 4 / USB4® 40Gbps (supports data transfer and DisplayPort™ 1.4)
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 2 (supports data transfer and DisplayPort™ 1.4)
1x USB-C® 3.2 Gen 2 (supports data transfer, Power Delivery 135W, and DisplayPort™ 1.4)
2x USB 3.2 Gen 1
Security Chip: Firmware TPM 2.0
Fingerprint Reader: None
Other Security: E-shutter
Service
Base Warranty: 1-year, Courier or Carry-in
Included Upgrade: 3Y ADP - IPMAIN (ESS), 3Y Legion Ultimate Support - IPMAIN (ESS)
Accessories
Bundled Accessories: Lenovo® Legion™ M300 RGB Gaming Mouse
Certifications
Green Certifications:
ErP Lot 3
RoHS compliant
